• Base 3000 mm, with hardened guides in x-direction, 3.000 – 8.000 mm
• Electric device – operation via 2-hand safety control, setting mode to adjust drilling depth – key switch
• Drilling units with stand and linear guides in X-direction, shafts for manual adjustment of drilling height, working range 125 mm (drill to back wall), Positioning in X and Y direction by scale, Profile height max. 200 mm
• Either toothed drill chucks or multy spindle heads available
• Drilling units, motor 1,5 KW, 400 V, 50 Hz, 3000 r.p.m., pneumatic down feed max. 200 mm, hydraulic damped
• Drilling performance up to Ø 16 mm
• Zero-stop for X-direction mounted on left side of machine, adjustable  0 – 100 mm
• Table with pneumatic horizontal profile clamps
