Suitable for working on steel and aluminum.
- Manual feed.
- Two-speed spindle by changing the position of the belt.
- Pneumatic copying pen in two stages.
- Pneumatic clamping of the spindle to the selected height.
- Large milling area despite a compact design.
- Easy tool change through self-releasing systems.
- Copy work in a ratio of 1: 1.
- Milling according to the stop or template.
- Milling of locking cylinders and handle holes up to 70 mm thick.
- Vertical milling area 240 × 120 mm.
- Vertical stroke 110 mm.
- Span of the profiles 220 × 100-270 × 130 mm.
- Speed of the rotating tool (blade speed) 2040-11200 rpm.
- Electrical frequency 50 Hz.
- Motor power 0.75 kW.
- Power supply (voltage) 230-400 ± 5% V.
- Compressed air connection 7 bar.
- Height of the machine ± 1700 mm.
- Width of the machine ± 800 mm.
- Length of the machine (total length) ± 800 mm.
- Machine weight ± 130 kg.
