Fully automatic operation with graphic control elements. 7.5 kW drive, 400V, 50 Hz. For HM or PCD saw blades Ø550 mm, max. 2850 rpm. Servo-controlled saw feed, vertically from below. Material feed via servo-controlled ball screw drive. Control Siemens S7 with 7 “touch display. Cutting area 270 x 150 mm (W X H). Remaining piece…
The high-performance automatic saw Profilma 250 is designed for cutting aluminum and non-ferrous metals to length with a particularly thin saw blade. Depending on the version, solid carbide circular saw blades Ø 250 mm with 1.6 mm width or Ø 200 mm with 1.2 mm width can be used on this machine. Compared to the…
Fully automatic operation cutting of aluminium and non-ferrous metal NC Control with touch screen display 5,7” Piece counter showing target/actual number of pieces Piece multiplier when cutting bundles Indication of cycle time Multiple feed device – max feed 3.250mm Table separation before the saw blade retracts so the profile is not touched by the saw blade…
Fully automatic operation Motor 7,5 KW, S6, 400V / 50 Hz, 2850 R.P.M. For the use of saw blade Ø 550 mm Big cutting range Max cutting height up to 150 mm Max cutting width up to 270 mm 90° cuts Remaining piece from 75 mm Table separation before sawblade retracts powered ball screw spindle…
High performance automatic circular saw for aluminum and non-ferrous metals Fully automatic operation Infinitely adjustable speed control of the saw blade engine Material and saw feeder movement through servo driven ball screw spindle 2 axis CNC control Siemens S7 with 7” touchscreen Cutting range: up to 205 mm height and up to 400 mm width…
